KeyboardExtAX

KeyboardExtAX accessibility snapshot illustration

Fast, read-only accessibility snapshots of active third-party iOS keyboard extensions in Simulator.

Why this project exists

A custom iOS keyboard runs in a separate app-extension process. When a client app presents that keyboard, ordinary UI automation usually sees the client application's accessibility tree but not the keyboard's useful descendants. The entire keyboard may appear as one opaque element.

That creates a practical automation gap:

screenshots can show the keyboard, but extracting reliable tap coordinates from pixels is slow and brittle;
the client application's accessibility snapshot does not necessarily expose the extension's keys and controls;
starting a new XCTest session for every query is expensive and can disturb keyboard focus;
XCTest element handles become stale whenever the keyboard changes layout;
automation agents should not need to manage test plans, ports, build products, or runner processes.

KeyboardExtAX fills that gap. It attaches XCTest directly to the already-running keyboard extension by bundle identifier, parses its accessibility hierarchy, and returns plain JSON with absolute logical coordinates. A persistent runner keeps warm snapshots fast, while a small controller owns building, caching, ports, and per-simulator lifecycle.

KeyboardExtAX observes only. Use a separate automation tool, such as XcodeBuildMCP, to launch apps, focus text fields, and perform gestures with the returned coordinates.

Quick start: MCP

Configure keyboard-ext-ax-mcp as a stdio MCP server. Most MCP clients use a configuration shaped like this:

config.json

{
  "mcpServers": {
    "KeyboardExtAX": {
      "command": "keyboard-ext-ax-mcp",
      "env": {
        "DEVELOPER_DIR": "/Applications/Xcode.app/Contents/Developer"
      }
    }
  }
}

If the MCP client does not inherit your shell PATH, replace the command with the absolute path printed by command -v keyboard-ext-ax-mcp.

The server exposes one tool:

text

keyboard_snapshot(
  simulator_id: "<SIMULATOR_UDID>",
  extension_bundle_id: "com.example.keyboard.extension",
  raw: false
)

Example input:

config.json

{
  "simulator_id": "2D78332B-A3C3-4CEE-962B-99EF531FD201",
  "extension_bundle_id": "com.example.keyboard.extension"
}

The result is returned as structured MCP content. The MCP layer delegates directly to the same controller used by the CLI, so build caching, sessions, errors, and output are identical.

Quick start: CLI

With the client text field focused and the requested keyboard visible:

keyboard-ext-ax snapshot \
  --simulator <SIMULATOR_UDID> \
  --extension com.example.keyboard.extension

Add --output /tmp/keyboard.json to write the result to a file. Add --raw for the nested tree and XCTest diagnostics.

Scope and limitations

KeyboardExtAX currently supports:

macOS hosts;
iOS Simulator;
third-party keyboard extensions;
Xcode 26.5;
read-only accessibility snapshots.

It does not:

tap, swipe, or type;
launch or foreground the client app;
select or enable a keyboard for the user;
access physical iOS devices;
guarantee compatibility with widgets, Live Activities, or other extension types;
guarantee parser compatibility with untested Xcode versions.

The parser reads XCUIApplication.debugDescription. Its text format is not a documented compatibility contract, so each Xcode version must be validated before support is claimed.

Requirements

macOS
Xcode 26.5 with the desired iOS Simulator runtime installed
Python 3.10 or newer
A keyboard app and extension already installed in the target simulator
The keyboard enabled in Settings → General → Keyboard → Keyboards
A foreground client app with a focused text field

If multiple Xcode installations are present, select one with DEVELOPER_DIR or --developer-dir:

server.ts

export DEVELOPER_DIR=/Applications/Xcode.app/Contents/Developer

Installation

Homebrew (recommended)

brew install nikitosina/tap/keyboard-ext-ax

PyPI with uv

Install both executables permanently:

uv tool install keyboard-ext-ax

Or run the MCP server without a persistent installation:

uvx keyboard-ext-ax mcp

From source

git clone https://github.com/Nikitosina/KeyboardExtAX.git
cd KeyboardExtAX
python3 -m venv .venv
.venv/bin/python -m pip install -e .
source .venv/bin/activate

Every installation provides keyboard-ext-ax and keyboard-ext-ax-mcp. The MCP server can be started with either keyboard-ext-ax-mcp or keyboard-ext-ax mcp.

The bundled Xcode project is ready to use. XcodeGen is needed only when modifying keyboard_ext_ax/harness/project.yml.

Output

The default response is a compact, flat array:

config.json

{
  "ok": true,
  "snapshot_id": "9543E2AA-C4D9-4281-9645-7792F7953FE3",
  "simulator_udid": "2D78332B-A3C3-4CEE-962B-99EF531FD201",
  "extension_bundle_id": "com.example.keyboard.extension",
  "pid": 12345,
  "elapsed_ms": 103.4,
  "round_trip_ms": 106.1,
  "session_reused": true,
  "total_ms": 171.8,
  "elements": [
    {
      "ref": "0.0.3",
      "type": "Key",
      "identifier": "space",
      "label": "Space",
      "frame": {
        "x": 112,
        "y": 746,
        "width": 178,
        "height": 44
      },
      "center": {
        "x": 201,
        "y": 768
      },
      "tap_x": 201,
      "tap_y": 768
    }
  ]
}

Element fields

Field	Meaning
`ref`	Stable path within this snapshot only. Refresh it after layout changes.
`type`	XCTest accessibility element type.
`identifier`	Accessibility identifier, when provided by the extension.
`label`	Accessibility label, when provided by the extension.
`frame`	Absolute logical frame in Simulator coordinates.
`center`	Exact floating-point frame center.
`tap_x`, `tap_y`	Rounded integer center, ready for a gesture tool.

Coordinates are Simulator logical coordinates, not screenshot pixels. Do not rescale them before passing them to XcodeBuildMCP for the same simulator.

Session management

keyboard-ext-ax status
keyboard-ext-ax status --simulator <SIMULATOR_UDID>
keyboard-ext-ax stop --simulator <SIMULATOR_UDID>
keyboard-ext-ax stop --all

One runner is maintained per simulator. Multiple simulators can be queried concurrently. If a reused runner loses the extension process, KeyboardExtAX recycles it once and returns client_refocus_required.

Errors

Errors are JSON objects with stable codes.

Code	Meaning	Recovery
`client_refocus_required`	A new or restarted runner is ready.	Refocus the client text field and repeat the request.
`extension_not_active`	XCTest could not attach after three attempts.	Confirm that the requested extension—not the system keyboard—is visible, then retry.
`runner_start_failed`	The persistent XCTest runner did not become ready.	Inspect the returned `log` and `log_tail`.
`build_failed`	The XCTest harness failed to build.	Inspect the returned build log and verify the selected Xcode.
`xcode_unavailable`	Xcode could not be located or queried.	Set `DEVELOPER_DIR` or pass `--developer-dir`.
`extension_bundle_id_missing`	The runner received no extension identifier.	Supply `extension_bundle_id`.
`snapshot_failed`	XCTest raised an unexpected snapshot error.	Retry with `raw: true` and inspect diagnostics.

The CLI exits with:

0 for success;
2 for a normal snapshot-state error such as inactive extension;
1 for lifecycle, build, or controller failures.

Architecture

text

MCP client / CLI
        │
        ▼
KeyboardExtAXController
  ├─ build cache
  ├─ per-simulator lock and state
  ├─ free-port allocation
  └─ XCTest runner lifecycle
        │  JSON over loopback TCP
        ▼
PersistentKeyboardExtAXTests
        │  XCUIApplication(bundleIdentifier:)
        ▼
Active keyboard extension process
        │
        ▼
Parsed tree → compact elements → MCP/CLI JSON

The host app included in this repository is XCTest scaffolding. Snapshot mode does not launch it and does not replace the consumer's foreground client app.

License

KeyboardExtAX is available under the MIT License.
