freeq
IRC server and client with AT Protocol (Bluesky) identity authentication, end-to-end encrypted channels, iroh QUIC transport, peer-to-peer DMs, and federated server-to-server clustering.
Users authenticate with their Bluesky identity via a custom SASL mechanism
(ATPROTO-CHALLENGE). Standard IRC clients connect as guests. Authenticated
users get their DID bound to their connection — visible via WHOIS, enforced
for nick ownership, and usable for DID-based bans, invites, and persistent ops.
Try it now: irc.freeq.at
For agents
freeq is meant to be used by software as well as people, so every surface an agent looks for exists and cross-links the others:
- llms.txt — the documentation index, linking raw markdown (llms-full.txt for one fetch).
- OpenAPI 3.1 — the full HTTP
contract (
spec/openapi.yaml; a drift test fails the build if the router and the spec disagree). - MCP — freeq-mcp/ (
@freeq/mcp) gives any MCP client tools to read, search, verify and take part in conversations. Not on npm yet: build it (cd freeq-mcp && npm install && npm run build) and point your client atnode <repo>/freeq-mcp/dist/index.js. - Skills —
skills/: freeq (talking to other people's agents), freeq-api (REST), freeq-bots (building one). - Agent Assistance Interface — ask the server why a join failed or a message went missing; it answers with a conclusion plus evidence, not raw state.
Attribution is the point: every message carries a ULID msgid and a signature,
and GET /api/v1/verify/{msgid} distinguishes a message signed by its author's
key from one merely relayed by the server.
Web Client
The web client at irc.freeq.at provides:
- AT Protocol OAuth login — sign in with your Bluesky identity
- Channel policy gates — channels can require credential verification to join
- GitHub verification — prove repo collaborator or org membership status
- Bluesky social graph gates — prove you follow someone (no OAuth needed)
- Moderator appointments — ops issue signed credentials for halfop (+h)
- Automatic role escalation — credentials auto-grant IRC modes (op, halfop, voice)
- Shareable invite links —
https://irc.freeq.at/join/#channel - Message editing, deletion, reactions, threads — changing a message requires the sender's signature; current clients sign automatically
- End-to-end encrypted channels
Demo Channels
| Channel | Policy | What it demonstrates |
|---|---|---|
#demo-follow | Must follow @chadfowler.com on Bluesky | Social graph verification (zero OAuth) |
#demo-github | Open join, freeq-irc/freeq collaborators get auto-op | Layered credentials + role escalation |
#demo-moderation | Open join, moderators appointed via credentials | Credential-based moderation pipeline |
Architecture
The SDK exposes a (ClientHandle, Receiver<Event>) pattern — any UI or bot
can consume events and send commands.
Transport Stack
All transports feed into the same handle_generic() handler — the IRC
protocol is transport-agnostic. Each transport is zero-cost when not enabled.
Quick Start
Build
Run the Server
Generate a self-signed cert for local development:
Connect with the TUI Client
Iroh auto-discovery: When connecting to a server that has --iroh
enabled, the TUI probes CAP LS for the iroh=<endpoint-id> capability
and auto-upgrades to iroh QUIC transport. No manual endpoint ID needed.
OAuth sessions are cached to ~/.config/freeq-tui/<handle>.session.json
so you don't need to re-authenticate on every launch.
Connect with a Standard IRC Client
Any IRC client works as a guest — irssi, WeeChat, HexChat, LimeChat, etc.
Connect to 127.0.0.1:6667 (plain) or 127.0.0.1:6697 (TLS). No special
configuration needed.
Connect via WebSocket
When --web-addr is set, the server accepts WebSocket connections at
ws://<addr>/irc. A test HTML client is included at freeq-server/test-client.html.
Authentication
SASL ATPROTO-CHALLENGE
The server implements a custom SASL mechanism for AT Protocol identity:
- Client requests
CAP sasl, thenAUTHENTICATE ATPROTO-CHALLENGE - Server sends a challenge:
base64url(json { session_id, nonce, timestamp }) - Client responds with one of:
- Crypto signature (
method: "crypto"): Signs challenge bytes with a private key listed in the DID document - PDS session (
method: "pds-session"): Sends an app-password JWT; server verifies against the PDS - PDS OAuth (
method: "pds-oauth"): Sends a DPoP-bound access token with proof; server verifies against the PDS
- Crypto signature (
- Server verifies, emits
903(success) or904(failure) - Client sends
CAP END, registration completes
Security Properties
- Each challenge contains a cryptographically random nonce
- Challenges are invalidated after use (no replay)
- Challenge validity window: configurable, default 60 seconds
- Private keys never leave the client
- PDS URL is verified against the DID document before accepting session tokens
- Supported key types: secp256k1 (MUST), ed25519 (SHOULD)
What Authentication Gets You
- Nick is bound to your DID — no one else can use it
- WHOIS shows your DID and Bluesky handle
- You can be banned or invited by DID (survives reconnect/nick changes)
- Persistent channel ops tied to your DID (survive reconnects and work across federated servers)
- Your identity is cryptographically verifiable
Transports
TCP / TLS (Standard)
Standard IRC on port 6667 (plain) and 6697 (TLS). TLS auto-detected by port in the client. Always available.
WebSocket
Enabled with --web-addr. Accepts WebSocket IRC at /irc. Uses the same
IRC wire protocol — WebSocket is a transport, not a new protocol. Includes
a read-only REST API at /api/v1/ (channels, members, topics, messages).
iroh (QUIC)
Enabled with --iroh. Provides NAT-traversing encrypted QUIC connections
via iroh. The server generates a persistent secret
key (iroh-key.secret) on first run — endpoint ID is stable across restarts.
The server advertises its iroh endpoint ID in CAP LS:
Clients auto-discover and upgrade to iroh when available.
End-to-End Encryption (E2EE)
Client-side channel encryption using AES-256-GCM with HKDF-SHA256 key derivation from a shared passphrase. The server relays ciphertext unchanged.
Wire format: ENC1:<nonce-b64>:<ciphertext-b64> — version-tagged, uses the
message body for robustness. All channel members must use the same passphrase.
Peer-to-Peer Encrypted DMs
Direct encrypted messaging between clients via iroh QUIC, bypassing the server entirely.
P2P conversations appear in dedicated p2p:<short-id> buffers. Wire format
is newline-delimited JSON (not IRC protocol). ALPN: freeq/p2p-dm/1.
P2P endpoint IDs are visible in WHOIS (numeric 672).
Server-to-Server Federation (S2S)
Servers cluster over iroh QUIC connections. Each server maintains its own local state and syncs channel membership, messages, topics, and DID-based ops across the federation.
Setup
Server A doesn't need --s2s-peers — it accepts incoming S2S connections
automatically when --iroh is enabled.
What Syncs
| Feature | Sync behavior |
|---|---|
| JOIN/PART/QUIT | Membership tracked per origin server |
| PRIVMSG | Channel messages relayed to all peers |
| TOPIC | Topic changes propagate |
| DID-based ops | Persistent ops sync via CRDT |
| Founder | First-write-wins CRDT resolution |
| NAMES | Includes both local and remote members |
| WHOIS | Shows DID, handle, and origin for remote users |
CRDT-Based State Convergence
Channel authority (founder, DID-based ops) uses Automerge CRDTs for conflict-free convergence. Presence is NOT in the CRDT — it's S2S event-driven to avoid ghost users when servers crash.
- Founder resolution: Deterministic min-actor-wins — concurrent claims converge deterministically, late entrants cannot overwrite after sync
- DID ops: Union merge — grants propagate, revocations propagate
- Provenance tracking: All CRDT writes carry origin peer + authorizing DID
- Authority boundaries: Soft enforcement validates who can write each key-space
- Event dedup: S2S events carry unique IDs; bounded LRU prevents replay
- Peer identity: CRDT sync keyed by iroh endpoint ID (cryptographic), not server name (untrusted). Hello handshake binds transport to logical identity.
- Compaction: Periodic snapshot + reload bounds doc growth in long-lived deployments
- Async-safe: CRDT uses
tokio::sync::Mutex— no runtime thread blocking - No timestamps in authority decisions (spoofable by rogue servers)
S2S Acceptance Tests
9 tests verify: connectivity, bidirectional message relay, NAMES sync, topic sync, PART/QUIT cleanup, and late-joiner state.
IRC Features
Standard IRC
Full compatibility with RFC 1459/2812 basics:
- NICK, USER, JOIN, PART, PRIVMSG, NOTICE, QUIT
- NAMES (query channel membership on demand)
- PING/PONG (client and server keepalive)
- WHOIS (shows DID, handle, iroh ID for authenticated users)
- CTCP ACTION (
/me) - Multiple channels, private messages
Channel Modes
| Mode | Description |
|---|---|
+o nick | Channel operator |
+v nick | Voice |
+b mask | Ban (hostmask *!*@host or DID did:plc:xyz) |
+i | Invite-only |
+t | Topic lock (ops only) |
+k key | Channel key (password) |
DID-Aware Features
- DID bans (
MODE #chan +b did:plc:xyz): Bans by identity, not just hostmask. Survives nick changes and reconnects. - DID invites (
INVITE nick #chan): If the user is authenticated, the invite is stored by DID and survives reconnect. - Nick ownership: Once an authenticated user claims a nick, guests and
other DIDs cannot use it. If an unauthenticated user tries to take a
registered nick during SASL negotiation, they're renamed to
GuestXXXXat registration time. - Persistent DID-based ops: When an authenticated user is opped, their DID is recorded. They're auto-opped on rejoin — even on a different server in the federation. Channel founders (first authenticated user to create a channel) can never be de-opped.
Message History
The server stores the last 100 messages per channel. When you join, recent history is replayed as standard PRIVMSG — works with any IRC client, no special protocol extension needed.
Rich Media (IRCv3 Message Tags)
Rich media is supported through IRCv3 message tags, giving multipart/alternative semantics — the same content in two representations:
- Tags: Structured metadata (content-type, URL, dimensions, alt text)
- Body: Plain text fallback (description + URL)
| Client | What they see |
|---|---|
| irssi, WeeChat | Sunset https://cdn.bsky.app/img/... (clickable link) |
| freeq-tui | 🖼 [image/jpeg] Sunset 1200×800 https://cdn.bsky.app/img/... |
Media is hosted externally (AT Protocol PDS blob storage). The IRC server never handles media bytes — it just relays tagged messages.
Supported tag keys:
| Tag | Description |
|---|---|
content-type | MIME type (e.g. image/jpeg, video/mp4) |
media-url | URL where the media can be fetched |
media-alt | Alt text / description |
media-w | Width in pixels |
media-h | Height in pixels |
media-blurhash | Blurhash placeholder |
media-size | File size in bytes |
media-filename | Original filename |
Rate Limiting
Token bucket rate limiter (10 commands/second) kicks in after registration. The initial connection burst is not rate-limited, so clients that send many commands on connect (like LimeChat) work correctly.
TUI Client
Status Bar
The status bar shows:
- Transport badge: Colored indicator (red=TCP, green=TLS, cyan=WS, magenta=Iroh)
- Nick: Your current nick
- Auth: Authenticated DID or "guest"
- Uptime: Connection duration
Keybindings
Emacs mode (default):
| Key | Action |
|---|---|
| Ctrl-A / Home | Beginning of line |
| Ctrl-E / End | End of line |
| Ctrl-F / Right | Forward char |
| Ctrl-B / Left | Back char |
| Alt-F | Forward word |
| Alt-B | Back word |
| Ctrl-D | Delete char |
| Ctrl-H / Backspace | Delete back |
| Ctrl-K | Kill to end of line |
| Ctrl-U | Kill to beginning |
| Ctrl-W | Kill word back |
| Alt-D | Kill word forward |
| Ctrl-Y | Yank (paste kill ring) |
| Ctrl-T | Transpose chars |
| Alt-U | Uppercase word |
| Alt-L | Lowercase word |
| Alt-C | Capitalize word |
| Tab | Nick completion |
| Up / Down | Input history |
| Ctrl-N / Alt-N | Next buffer |
| Ctrl-P / Alt-P | Previous buffer |
| BackTab (Shift-Tab) | Previous buffer |
| PageUp / PageDown | Scroll messages |
| Ctrl-C / Ctrl-Q | Quit |
Vi mode (--vi):
Normal mode: h/l move, w/b/e word motion, 0/$ line edges,
i/a/I/A enter insert, x/X/D/C/S/s delete/change, p/P paste,
k/j history, dd clear line. Insert mode: standard typing, Esc to
exit to normal mode.
Commands
Network Info Popup (/net)
Shows: transport type, server address, connection state, uptime, nick,
authenticated DID, iroh endpoint ID, E2EE channels, P2P DM status.
Close with Esc or q.
Debug Mode (/debug)
Toggles raw IRC line display in the status buffer (prefixed with ←).
Useful for diagnosing protocol issues.
REST API
When --web-addr is set, a read-only REST API is available:
| Endpoint | Description |
|---|---|
GET /api/v1/channels | List all channels |
GET /api/v1/channels/{name} | Channel info (topic, modes, member count) |
GET /api/v1/channels/{name}/members | Channel member list |
GET /api/v1/channels/{name}/topic | Channel topic |
GET /api/v1/channels/{name}/messages | Recent messages (with pagination) |
GET /api/v1/stats | Server stats |
All writes go through IRC — the REST API is strictly read-only.
Server Configuration
Persistence
When --db-path is set, the server persists:
- Message history — all channel messages, queryable with pagination
- Channel state — topics, modes (+t, +i, +k), channel keys
- Bans — hostmask and DID bans survive restarts
- DID-nick bindings — nick ownership persists across server restarts
Without --db-path, the server runs entirely in-memory. The database uses SQLite with WAL mode for good concurrent read performance. Persistence failures are logged but do not crash the server.
Every flag can also live in a TOML file passed via --config server.toml (or FREEQ_CONFIG): keys are the flag names with underscores (listen_addr = "0.0.0.0:6667"), lists are arrays, and precedence is CLI flag > environment variable > file > default, so existing flag-based deployments work unchanged. A typo'd key is a startup error that names the key. --migrate-to is deliberately CLI-only. A full worked example ships as server.toml.example, and a test keeps it in sync with the real schema.
Schema migrations run automatically (and upward only) at startup. A server binary refuses to open a database stamped with a newer schema than it knows, so before rolling back to an older binary, downgrade the schema first: freeq-server --db-path <PATH> --migrate-to <VERSION> runs the ladder to the named version and exits. Downgrades stop with an error at any migration that is irreversible by design.
Deployment
See deploy/README.md for example VPS setup and deployment instructions.
Tests
153 tests covering:
- SDK (44): IRC parsing (with tag support), tag escaping roundtrip, DID document parsing, key generation/signing/verification, multibase/multicodec, challenge response encoding, SASL signer variants, media attachment roundtrip, link preview roundtrip, media type detection
- Server unit (33 + 12 CRDT): Message parsing (with tags), tag escaping, SASL challenge store (create, take, replay, expiry, forged nonce), channel state, database roundtrips (channels, bans, messages, identities), CRDT tests (founder deterministic min-actor, founder not overwritten after sync, DID ops sync, topic provenance, authority validation, compaction, metrics, ban provenance)
- Integration (27): Guest connection, secp256k1 auth, ed25519 auth, wrong key rejection, unknown DID rejection, expired challenge rejection, replayed nonce rejection, channel messaging, mixed auth/guest, nick collision, channel topic, topic lock, channel ops/kick, hostmask bans, DID bans, invite-only, message history replay, nick ownership, quit broadcast, channel key (+k), TLS connection, rich media tag passthrough, persistence (messages, topics, bans, nick ownership survive restart)
- S2S acceptance (9): Connectivity, bidirectional message relay, NAMES sync, topic sync, PART/QUIT cleanup, late-joiner state
Protocol Notes
Deviations from the Spec
- Challenge uses JSON encoding (not a binary format) for debuggability
- PDS session verification is an additional auth method beyond the spec's crypto-only approach — it enables OAuth login without requiring users to manage raw signing keys
- History replay uses standard PRIVMSG (no custom extension or batch)
IRCv3 Compatibility
- CAP negotiation follows IRCv3
CAP LS 302/CAP REQ/CAP END - SASL flow follows IRCv3 SASL specification with a custom mechanism name
message-tagscapability follows the IRCv3 message tags specification- Media tags use vendor-prefixed names (
content-type,media-url, etc.) - Server advertises
iroh=<endpoint-id>inCAP LSfor transport discovery ATPROTO-CHALLENGEcould be proposed as an IRCv3 WG mechanism
Plugins
Freeq supports a plugin system for custom server behavior. Plugins hook into events like authentication, message delivery, and channel joins.
See examples/plugins/ for example configurations and docs/PROTOCOL.md
for the full plugin hook reference.
Documentation
- Features — Complete feature catalog
- Protocol Notes — SASL mechanism, DID extensions, transport details
- Known Limitations — Explicit list of gaps
- Architecture Decisions — Design rationale
- S2S Audit — Federation protocol analysis
- CRDT Federation Audit — CRDT convergence issues & fix plan
- Future Direction — Roadmap
License
MIT
