# J-Link MCP [Health: Active] **Category:** 💻 Developer Tools **Repository:** https://github.com/Klievan/jlink-mcp **GitHub Stars:** 29 **Views:** 0 **Installs:** 0 **Upvotes:** 0 **Directory Page:** https://allmcps.com/mcp/j-link-mcp ## Description Debug embedded firmware on real hardware: J-Link probes, Cortex-M faults, RTT logs, GDB. ## Claude Desktop Quick Installation Install path detected from listing signals. Uses `npx` (confidence: high): ```json "mcpServers": { "j-link-mcp": { "command": "npx", "args": ["-y","jlink-mcp"] } } ``` ## Documentation & README

jlink-mcp

Give AI hands to touch silicon.
An MCP server that lets LLMs debug embedded devices through SEGGER J-Link probes.

--- ## See it work

A terminal session: the MCP server finds the probe, flashes firmware, opens a debug session, streams RTT logs, injects a fault, and decodes the resulting HardFault — naming the faulting instruction.

Real MCP tool calls against a real nRF52840-DK. Reproduce it yourself: npm run demo

Your firmware just crashed. One tool call: ``` > diagnose_crash ## Crash Diagnosis ### CPU State Core: PC=0x000000B8 SP=0x2003FFA8 R0=0x0000000A R1=0x000007FF R2=0x00000001 ... Status: XPSR=0x21000003 CONTROL=0x00000000 PRIMASK=0x00000000 ... Stack: MSP=0x2003FFA8 PSP=0x00000000 ⚠ CPU is in exception handler (IPSR=0x00000003) ### Fault Registers CFSR=0x01000000 HFSR=0x40000000 DFSR=0x00000000 MMFAR=0xe000edf8 BFAR=0xe000edf8 ### Decoded Faults ## UsageFault (UFSR): - UNALIGNED: Unaligned memory access ## HardFault (HFSR): - FORCED: Forced HardFault (escalated from configurable fault) ### Exception Stack Frame R0 = 0x0000000A R1 = 0x000007FF R12 = 0x00000000 LR = 0x000001F5 PC = 0x00000254 xPSR = 0x21000000 → Faulting instruction at PC=0x00000254 ### Recent Errors/Warnings from RTT [WRN] sensor_drv: sample out of range, clamping seq=2 ``` Fault decoded, exception frame unwound, faulting instruction named, and the device's own log correlated — from one call, without a human reading a datasheet to find out what bit 24 of CFSR means. ### And it knows what the silicon is Point it at your target's CMSIS-SVD file and peripheral registers stop being hex: ``` > read_peripheral FICR FICR @ 0x10000000 INFO.PART @ 0x10000100 = 0x00052840 (read-only) [31:0] PART 0x52840 → N52840 INFO.RAM @ 0x1000010C = 0x00000100 (read-only) [31:0] RAM 0x100 → K256 INFO.FLASH @ 0x10000110 = 0x00000400 (read-only) [31:0] FLASH 0x400 → K1024 ``` `0x400` means 1024 KB of flash — but only if you know that, and an LLM guessing at bit layouts is exactly the failure this avoids. The addresses come from the vendor's own description, and the meanings from its enumerations. *Both transcripts are verbatim output from an nRF52840-DK in this project's hardware test suite.* ## What is this? **jlink-mcp** connects AI assistants (Claude, Copilot, etc.) to your embedded hardware via [SEGGER J-Link](https://www.segger.com/products/debug-probes/j-link/) debug probes using the [Model Context Protocol](https://modelcontextprotocol.io). Instead of manually typing J-Link commands, your AI assistant can: - **Read registers and memory** to understand device state - **Flash firmware** and reset devices - **Stream RTT logs** and search them by level/module/regex - **Diagnose crashes** by auto-decoding ARM Cortex-M fault registers - **Control execution** — halt, step, resume, breakpoints - **Start GDB servers** for full debugging sessions > Also supports **OpenOCD** (ST-Link, CMSIS-DAP, FTDI) and **Black Magic Probe** backends. ## Installing You need the [SEGGER J-Link software](https://www.segger.com/downloads/jlink/) — that is what this server drives — a probe connected to an ARM Cortex-M target, and Node 18+. For the other backends, OpenOCD or `arm-none-eabi-gdb` instead. **Claude Code** — from the plugin marketplace. This brings the `embedded-debugging` skill along with the server, which is what stops an assistant guessing at your hardware: ``` /plugin marketplace add Klievan/jlink-mcp /plugin install jlink-mcp ``` **Any other agent** — point it at this repository and ask it to set itself up: > Install the MCP server at https://github.com/Klievan/jlink-mcp and configure > it for my board. It will find what it needs here. If you would rather do it by hand, the server is on npm and needs no build step: `npx -y jlink-mcp`, with `JLINK_DEVICE` set to your target. [`mcp-config.json`](https://github.com/Klievan/jlink-mcp/blob/HEAD/mcp-config.json) is a config you can paste. **VS Code** — install [the extension](https://marketplace.visualstudio.com/items?itemName=Klievan.jlink-mcp). It registers the server for Copilot Chat, Claude, and any MCP-aware client, so there is nothing to configure. ### Then check it Ask for `check_setup`. One call, and it says what is missing and what to do: ``` Not ready to debug yet. OK probe software — J-Link software found at /Applications/SEGGER/JLink BLOCK probe — none detected (Connecting to J-Link via USB...FAILED). Check the USB cable. BLOCK target device — not set. Find the exact name with search_devices, then set_device. note SVD — not loaded, so peripheral reads stay raw hex. Set SVD_PATH to a CMSIS-SVD file. ``` You do not need your device's exact part number up front. `search_devices` searches all 9800 that J-Link supports, by part number, manufacturer, or core. ## Tools (47) ### Workflow Tools (start here) | Tool | Description | |------|-------------| | `start_debug_session` | **One-call setup.** Starts GDB server + connects RTT + returns boot log. | | `snapshot` | Captures full device state: registers, fault status, stack dump, RTT output. | | `diagnose_crash` | Auto-reads and decodes ARM Cortex-M fault registers (CFSR, HFSR, MMFAR, BFAR) with exception stack frame. | ### Device Setup | Tool | Description | |------|-------------| | `list_devices` | Scan for connected probes and show the configured target | | `set_device` | Change the target device at runtime — no restart needed | | `get_config` | Current probe, target device, and GDB server state | ### Device Control | Tool | Description | |------|-------------| | `device_info` | Probe type, target CPU, compact register summary | | `halt` | Halt CPU | | `resume` | Resume CPU | | `reset` | Reset device. `halt` stops it at the reset vector; `strategy` picks a [J-Link reset type](https://kb.segger.com/J-Link_Reset_Strategies), or omit it and let J-Link choose | | `step` | Single-step one instruction | ### Peripherals (CMSIS-SVD) Set `jlinkMcp.svdPath` to your target's SVD — the same file Cortex-Debug takes as `svdFile`. Vendors publish one per part. | Tool | Description | |------|-------------| | `list_peripherals` | Every peripheral and base address on the chip | | `read_peripheral` | Read a peripheral's registers and decode each one's bit fields by name | | `decode_register` | Decode one register — read from the device, or interpret a value you already have | ### Memory & Registers | Tool | Description | |------|-------------| | `read_memory` | Read memory at address (clean hex dump output) | | `write_memory` | Write 32-bit value to address | | `read_registers` | All CPU registers in compact format | | `read_register` | Read specific register (PC, SP, R0-R12, etc.) | ### Flash | Tool | Description | |------|-------------| | `flash` | Flash .hex/.bin/.elf firmware to device | | `erase` | Erase entire flash | ### Breakpoints | Tool | Description | |------|-------------| | `set_breakpoint` | Set hardware breakpoint at address | | `clear_breakpoints` | Clear all breakpoints | ### GDB Server | Tool | Description | |------|-------------| | `gdb_server_start` | Start probe's GDB server | | `gdb_server_stop` | Stop GDB server + disconnect RTT | | `gdb_server_status` | GDB server, RTT, and proxy status | ### Source-Level Debugging Attach a real GDB client for symbol-aware work — backtraces, variable inspection, and stepping by source line rather than by instruction. | Tool | Description | |------|-------------| | `gdb_connect` | Attach a GDB client (auto-starts the server; optional ELF for symbols) | | `gdb_load` | Load an ELF for debug symbols, optionally flashing it too | | `gdb_backtrace` | Call stack, optionally with locals in each frame | | `gdb_command` | Run any GDB command — `print sensor_state`, `info threads`, `break main` | | `gdb_wait` | Wait for the target to stop (after a continue or a breakpoint) | | `gdb_disconnect` | Detach the client, clearing breakpoints and debug hardware | ### RTT (Real-Time Transfer) | Tool | Description | |------|-------------| | `rtt_connect` | Connect to RTT telnet port | | `rtt_disconnect` | Disconnect from RTT | | `rtt_read` | Read recent log lines (ANSI stripped, Zephyr format parsed) | | `rtt_search` | **Filter logs** by level (`err`/`wrn`/`inf`/`dbg`), module, or regex | | `rtt_send` | Send data to device via RTT down-channel | | `rtt_clear` | Clear RTT buffer | ### Telnet Proxy (Trice / Pigweed) | Tool | Description | |------|-------------| | `telnet_proxy_start` | Start TCP proxy that tees RTT for external detokenizers | | `telnet_proxy_stop` | Stop proxy | | `telnet_proxy_status` | Proxy connection status | | `telnet_proxy_read` | Read raw proxy buffer | ### Advanced | Tool | Description | |------|-------------| | `probe_command` | Execute raw probe commands | | `get_config` | Current probe and server configuration | ## The status bar knows who has the probe A J-Link serves one client at a time, so a GDB server left running blocks everything else — and the usual way that happens is an assistant starting one through MCP and nobody noticing. The extension cannot detect that by remembering what it did: the MCP server runs in a separate process, so an LLM-started server is invisible to it. So it watches the GDB port instead, which is true whoever is responsible. When something is listening the status bar turns amber and reads **J-Link · MCP · 47m** — who started it, and how long ago. Those are the two facts that turn "something has the probe" into "the assistant has had it since before lunch". Clicking offers to stop it. The tooltip carries the rest: device, ports, whether RTT is up, and why it matters. And it never claims an uptime it did not watch — a server that was already running when the window opened is reported as *known about* for that long, not *up* for it. It will not kill a process it cannot identify as a J-Link GDB server. A listening port proves something is there, not that it is ours. ## The skill The tools tell a model *what it can do*. They do not tell it what is worth doing, and two things go wrong constantly without that: models never think to load the ELF, so every backtrace is bare addresses; and they reason about what the hardware should be doing instead of spending one call asking it. `skills/embedded-debugging/SKILL.md` is a Claude Code skill that covers both — the two files that change everything (ELF for names, SVD for meanings), the halt/read/resume rule, workflows for crashes, hangs, peripherals and silent devices, and a table of beliefs paired with the tool call that actually checks each one. Claude Code picks it up if you install this repo as a plugin (`.claude-plugin/plugin.json`), or you can copy the directory into `.claude/skills/` in your firmware project. MCP itself has no notion of skills — its portable equivalent is prompts, and this server ships four. Its claims are tested. `test/hil/s04-symbols.test.ts` proves on real silicon that a backtrace without symbols has no function names, that loading the ELF gives them, and that a symbols-only load does not reprogram the device. ## Multi-Probe Support jlink-mcp supports multiple debug probe backends through a common `ProbeBackend` abstraction: | Backend | Probe Hardware | Status | RTT Support | |---------|---------------|--------|-------------| | **J-Link** | SEGGER J-Link, J-Link OB, J-Link EDU | Production | Yes | | **OpenOCD** | ST-Link, CMSIS-DAP, FTDI, J-Link (via OpenOCD) | Beta | No | | **Black Magic Probe** | BMP (built-in GDB server on serial) | Beta | No | | **probe-rs** | All probe-rs supported probes | Planned | Planned | ### Selecting a Backend ```bash # J-Link (default) PROBE_TYPE=jlink JLINK_DEVICE=nRF52840_XXAA node out/mcp/standalone.js # OpenOCD with ST-Link PROBE_TYPE=openocd \ OPENOCD_INTERFACE=interface/stlink.cfg \ OPENOCD_TARGET=target/stm32f4x.cfg \ node out/mcp/standalone.js # Black Magic Probe PROBE_TYPE=blackmagic \ BMP_SERIAL_PORT=/dev/ttyACM0 \ node out/mcp/standalone.js ``` ## Architecture ``` ┌─────────────────────────────────────────────────────┐ │ MCP Client │ │ (Claude, Copilot, any MCP client) │ └──────────────────────┬──────────────────────────────┘ │ JSON-RPC over stdio ┌──────────────────────▼──────────────────────────────┐ │ jlink-mcp │ │ │ │ ┌──────────┐ ┌──────────┐ ┌───────────────────┐ │ │ │ 31 Tools │ │4 Resources│ │ 4 Prompts │ │ │ └────┬─────┘ └────┬─────┘ └───────┬───────────┘ │ │ │ │ │ │ │ ┌────▼──────────────▼────────────────▼───────────┐ │ │ │ ProbeBackend │ │ │ │ ┌─────────┐ ┌─────────┐ ┌──────────────────┐ │ │ │ │ │ J-Link │ │ OpenOCD │ │ Black Magic Probe│ │ │ │ │ └────┬────┘ └────┬────┘ └────────┬─────────┘ │ │ │ └───────┼───────────┼───────────────┼─────────────┘ │ │ │ │ │ │ │ ┌───────▼───┐ ┌─────▼────┐ ┌───────▼──────────┐ │ │ │ RTTClient │ │TelnetProxy│ │ ProcessManager │ │ │ └───────────┘ └──────────┘ └──────────────────┘ │ └─────────────────────────────────────────────────────┘ │ ┌────────────▼────────────┐ │ Debug Probe (USB) │ │ → Target MCU (SWD/JTAG)│ └─────────────────────────┘ ``` ### Source Layout ``` src/ ├── probe/ │ ├── backend.ts # ProbeBackend abstract class + shared utilities │ ├── jlink.ts # SEGGER J-Link implementation │ ├── openocd.ts # OpenOCD implementation │ ├── blackmagic.ts # Black Magic Probe implementation │ └── factory.ts # Probe creation from config ├── mcp/ │ ├── server.ts # MCP server (45 tools, 4 resources, 4 prompts) │ └── standalone.ts # Standalone entry (stdio transport) ├── rtt/ │ └── rtt-client.ts # RTT client with ANSI stripping + Zephyr log parsing ├── telnet/ │ └── telnet-proxy.ts # TCP proxy for Trice/Pigweed detokenizer ├── utils/ │ ├── config.ts # VSCode settings / env var config │ ├── logger.ts # Logging │ └── process-manager.ts # Child process lifecycle └── extension.ts # VSCode extension + MCP provider registration ``` ## Design Decisions (LLM-Optimized) This server was built by having an AI use it against real hardware, then fixing every friction point. ### What `read_registers` would give you Raw `JLinkExe` output for `halt; regs` — **77 lines**, of which about six carry information. Every token here costs context, and the register values are buried in the middle: ``` SEGGER J-Link Commander V9.70 (Compiled Aug 19 2026 12:16:13) DLL version V9.70, compiled Aug 19 2026 12:15:25 Connecting to J-Link ...O.K. Firmware: J-Link OB-nRF5340-NordicSemi compiled Jun 11 2026 13:12:28 Hardware version: V1.00 J-Link uptime (since boot): 0d 00h 34m 29s S/N: 1050298247 License(s): RDI, FlashBP, FlashDL, JFlash, GDB ...30 more lines of connect banner... PC = 00000044, CycleCnt = 00EB67E5 R0 = 20000000, R1 = 9D56C547, R2 = 00000000, R3 = 00000000 ... FPS0 = 00000000, FPS1 = 00000000, FPS2 = 00000000, FPS3 = 00000000 ...28 more lines of zeroed FP registers... ``` ### What it actually gives you **Three lines.** Same information, grouped by what you would ask for: ``` Core: PC=0x00000046 SP=0x20010000 R0=0x20000000 R1=0x01D43416 R2=0x00000000 ... Status: XPSR=0x01000000 CONTROL=0x00000000 PRIMASK=0x00000000 BASEPRI=0x00000000 Stack: MSP=0x20010000 PSP=0x00000000 ``` Both captured from the same board. The rest of the design follows the same rule — return what was asked for, and nothing else: - **Output parsing** strips the connection banner. Only data comes back. - **Registers** are compact and grouped (core / status / stack). - **FP registers** only shown if non-zero (they're usually all zeros). - **RTT output** has ANSI escape codes stripped and Zephyr log format parsed into structured fields. - **Composite tools** (`start_debug_session`, `snapshot`, `diagnose_crash`) replace multi-step workflows with single calls. - **Fault decoding** is automatic — reads CFSR/HFSR/MMFAR/BFAR and explains each bit. - **`rtt_search`** lets you find errors without reading the entire log. - **Peripheral registers** decode through the vendor's own CMSIS-SVD, so the model reads `RAM = K256` rather than guessing what `0x100` means in that field of that register. - **Failures say what to do.** "Target is running; use halt" beats "could not read memory", and a fault-register read that did not happen reports itself rather than decoding zeroes into "no faults detected". ## Verified on real hardware Most of what can go wrong between an LLM and a debug probe fails *quietly*: a tool returns success with an empty payload, a parser drops half a line, a session dies and the next command reports something plausible instead. None of that is visible from reading the code, and a test suite that asserts "the call did not error" passes on all of it. So this project runs a hardware tier: **58 tests against a real nRF52840-DK** on a self-hosted runner, driving the actual MCP server over stdio exactly as a client would. It covers probe discovery, flash and verify, halt/step/resume under a live GDB session, memory and peripheral reads, RTT streaming and filtering, and crash diagnosis against faults injected on demand. It has caught bugs that had been shipping green, including: - `diagnose_crash` reporting **"No faults detected" during real crashes** — the memory-dump parser was dropping half of every line - **every GDB-routed tool returning empty output** while the server reported itself healthy - sessions leaving the target **unbootable**, with breakpoint comparators still armed that no reset clears - `reset` reporting success while **doing nothing at all** — the GDB server is a synchronous remote and refuses commands while the target runs, so every command of the reset sequence was rejected in turn and the failure discarded - the session teardown that disarms debug hardware being **refused in its entirety** for the same reason, and reporting "debug hardware disarmed" regardless — the fix above is what made this one visible - a GDB server reported **running when it had already exited**, because startup returned on the spawn without waiting to see whether it got the probe - **RTT going silent after a reset or a flash** — the target was still logging and the probe had stopped collecting, which reads exactly like a quiet device. Caught by reading the control block from both ends: 490 bytes written by the firmware, none collected - an **assignment that was silently discarded**, taking RTT out for the rest of the session — the flag guarding it asked whether a state enum read `GDB_RUNNING`, when the question it meant to ask was whether the GDB server was running Every one of those reported success. That is the point of the hardware tier, and the reason the suites assert on parsed content rather than on the call having returned without error — a suite that checked for errors would have passed on all of them. Raw probe output captured during those runs is committed as golden transcripts, so a fast unit tier replays real device bytes in seconds on any machine — no probe required to catch a format regression. ```bash npm test # ~257 tests, seconds, no hardware npm run test:hil # hardware tier; needs HIL=1 and a probe ``` ## Environment Variables ### J-Link | Variable | Default | Description | |----------|---------|-------------| | `PROBE_TYPE` | `jlink` | Probe backend: `jlink`, `openocd`, `blackmagic` | | `JLINK_DEVICE` | `Unspecified` | Target device (e.g., `nRF52840_XXAA`, `STM32F407VG`) | | `JLINK_INSTALL_DIR` | Auto-detect | Path to SEGGER J-Link installation | | `JLINK_INTERFACE` | `SWD` | Debug interface: `SWD` or `JTAG` | | `JLINK_SPEED` | `4000` | Connection speed in kHz | | `JLINK_SERIAL` | | J-Link serial number (multi-probe) | | `JLINK_GDB_PORT` | `2331` | GDB server port | | `JLINK_RTT_PORT` | `19021` | RTT telnet port | | `JLINK_RTT_ADDR` | Auto | Address of the RTT control block (your `_SEGGER_RTT` symbol). J-Link finds this by scanning RAM but never reports it back — supplying it is what lets RTT survive a target reset | ### OpenOCD | Variable | Default | Description | |----------|---------|-------------| | `OPENOCD_BINARY` | `openocd` | Path to openocd binary | | `OPENOCD_INTERFACE` | `interface/stlink.cfg` | Interface config file | | `OPENOCD_TARGET` | `target/stm32f4x.cfg` | Target config file | | `OPENOCD_GDB_PORT` | `3333` | GDB server port | | `OPENOCD_TELNET_PORT` | `4444` | Telnet command port | ### Black Magic Probe | Variable | Default | Description | |----------|---------|-------------| | `BMP_GDB_PATH` | `arm-none-eabi-gdb` | Path to GDB binary | | `BMP_SERIAL_PORT` | `/dev/ttyACM0` | BMP serial port | | `BMP_TARGET_INDEX` | `1` | Target index after scan | ## Contributing Adding a new probe backend: 1. Create `src/probe/yourprobe.ts` implementing `ProbeBackend` 2. Add a case to `src/probe/factory.ts` 3. That's it — all 31 MCP tools work automatically ## License MIT - see [LICENSE](https://github.com/Klievan/jlink-mcp/blob/HEAD/LICENSE) ---
